Twin Screw Extruder
Twin Screw Extruder- Side cutting type, it is old and traditional type, common to use.

Twin screw extruder- front cutting type.   Front cutting is more convenient to adjust the knife position.

1. Twin screw extruder are consisting of feeding system, extruding system, cutting system, heating system, and Gearing system and controlling system.

2. Feeding system, extruding system and cutting system, adopts frequency speed controlling with high automation and stable per-formation.

3. Automatic lubrication and cooling system guarantee the extruder running safely.

4. According to different material, we can choose the relative single or double screw feeding system; the material should be uniformity and stable.

5. Screw is made by special technique, is able to bear grinding, steady and reliable, longer using life.

6. According to different screws design rate to meet different technology request.

7. Parameter

Model

Main power

Capacity

Dimension

DP65

22kw

120-150kg/h

2.6x0.9x1.7m

DP70

45kw

200-250kg/h

2.8x0.9x1.7m

DP85

75kw

300-500kg/h

3.4x1.0x1.9m
