Features
- Widely suitable for premix, complete formula feed, additives, food, chemical and medicine industry etc. powder material mix.
- Discharging door adopted full open structure and big angle (>90° )，ensure material complete discharge and decrease
vestigital. - The discharging door molding rubber seal to ensure no leakage material.
- The gap between blade and casing ≤ 3mm and mixing uniformity CV ≤ 5%(can even reach 2.3%), high mixing uniformity.
- Mixing without dead angle, short cycle, mix time is about 30-120 seconds each batch, discharging time is about 3 minutes.
- Shaft end adopts packing seal, without leakage material, big access door structure, easy for clean and change paddle.
- Equipped with oil liquid adding system, can add variety of liquid.
- Liquid Sprayer adopted atomization, according to the need can install pneumatic assist sprayer and easy control.
- According to the need can choose stainless steel or semi-stainless steel or carbon steel material to manufacture.
- Double reduction gear belt drive, smooth transmission, save 20% power than chain drive.
- Low wearing of the belt, easy to maintenance and repair.
- Material mixing uniformity in zero gravity, not affected by material particle size, density and other factors.
- The machine structure compacts with good shape, covers an area of space less than other mixing equipment.
Specification and models
| Model | Effective volume (m³) | Yield per batch (kg) | Mixing time (s) | Batch mixing uniformity (CV% ≤) | Power (kw) |
| SSHJ0.1 | 0.1 | 50 | 30-120 | 5 | 2.2 / 3 |
| SSHJ0.2 | 0.2 | 100 | 30-120 | 5 | 3/4 |
| SSHJ0.5 | 0.5 | 250 | 30-120 | 5 | 5.5 / 7.5 |
| SSHJ1 | 1 | 500 | 30-120 | 5 | 11/15 |
| SSHJ2 | 2 | 1000 | 30-120 | 5 | 15 / 18.5 |
| SSHJ3 | 3 | 1500 | 30-120 | 5 | 22 |
| SSHJ4 (S) | 4 | 2000 | 30-120 | 5 | 22/30 |
| SSHJ6 (S) | 6 | 3000 | 30-120 | 5 | 37/45 |
| SSHJ8 (S) | 8 | 4000 | 30-120 | 5 | 45/55 |
| SSHJ12 (S) | 12 | 6000 | 30-120 | 5 | 75/90 |
